Robot LB-Series LiFePO₄ Batteries (Metal Casing)

Why Choose LB-SeriesLB100Ah / 51.2VTALB230Ah / 51.2VLB300Ah / 51.2VLB100Ah / 25.6V

Why Choose LB-Series

  • Long life, low downtime: Up to thousands of cycles with ≥95% Depth of Discharge for maximum usable energy.
  • Tough metal housing: Built for demanding environments with precise voltage and current accuracy and temperature monitoring.
  • Smart BMS & safety: Adjustable over-current and short-circuit protection with buzzer alarm, SOC/SOH estimation, and cell balancing.
  • Clear visibility: LED status bar plus LCD screen for real-time state-of-charge.
  • Easy integration: Standard RS232/RS485/CAN, host-computer monitoring, parallel communication, and support for 1–5 modules in a system.
  • Wide operating window: Discharge −10°C to +50°C; charge 0°C to +60°C. Low self-consumption with sleep & wake modes.



LB100Ah / 51.2VTA

Best for: General-purpose robots, AGVs/AMRs, cabinets where a 5 kWh class pack fits.

  • Energy / Voltage: 5,120 Wh at 51.2 V
  • Max Continuous Discharge: 100 A
  • Max Output Power: 5,120 W
  • Recommended Charge Current: 50 A
  • Cycle Life: ≥5,000 cycles
  • Charging (51.2 V series): Max 58.4 V; recommended 57.6 V
  • Size / Weight: 720 × 480 × 170 mm; 54.5 kg
  • I/O & Display: RS232/RS485/CAN; LED strip + LCD
  • Terminals / Expansion: M8; connect 1–5 modules
  • Environment: DOD ≥95%; storage −20–45°C (≤1 month), 0–35°C (1 month)

LB230Ah / 51.2V

Best for: High-draw robotics, mobile power carts needing 10 kW peak class.

  • Energy / Voltage: 11,776 Wh at 51.2 V
  • Max Continuous Discharge: 100 A / 200 A (model options)
  • Max Output Power: 5,120 W / 10,240 W (model options)
  • Recommended Charge Current: 100 A / 115 A (model options)
  • Cycle Life: ≥5,000 cycles
  • Charging (51.2 V series): Max 58.4 V; recommended 57.6 V
  • Size / Weight: 750 × 480 × 320 mm; 98.8 kg
  • I/O & Display: RS232/RS485/CAN; LED strip + LCD
  • Terminals / Expansion: M8; connect 1–5 modules
  • Environment: DOD ≥95%; full BMS protections and alarm

LB300Ah / 51.2V

Best for: Heavy-duty, long-shift platforms and energy storage with extended life.

  • Energy / Voltage: 14,336 Wh at 51.2 V
  • Max Continuous Discharge: 200 A
  • Max Output Power: 10,240 W
  • Recommended Charge Current: 140 A
  • Cycle Life: ≥8,000 cycles
  • Charging (51.2 V series): Max 58.4 V; recommended 57.6 V
  • Size / Weight: 885 × 585 × 435 mm; 114.72 kg
  • I/O & Display: RS232/RS485/CAN; LED strip + LCD
  • Terminals / Expansion: M8; connect 1–5 modules
  • Environment: DOD ≥95%; low-power and sleep modes

LB100Ah / 25.6V

Best for: Compact robots, small cabinets, and 24 Vdc systems.

  • Energy / Voltage: 2,560 Wh at 25.6 V
  • Max Continuous Discharge: 100 A
  • Max Output Power: 2,560 W
  • Voltage Range: ~21.6–29.2 Vdc (model-specific)
  • Charging (25.6 V model): Datasheet lists 26.2±0.2 V and 27.8±0.2 V items; follow the specific label on your unit for max/recommended charge settings.
  • Recommended Charge Current: 50 A
  • Cycle Life: ≥5,000 cycles
  • Size / Weight: 532 × 347 × 170 mm; 30 kg
  • I/O & Display: RS232/RS485/CAN; LED strip + LCD
  • Terminals / Expansion: M8; connect 1–5 modules
